Types and Variants of 2.92 mm Connectors
Depending on the application, 2.92 mm connectors come in various configurations:
Straight vs. Right-Angle: For different PCB or cable routing needs.
Jack (Female) vs. Plug (Male): To match system requirements.
Cable-to-Board: For connecting coaxial cables directly to printed circuit boards.
Panel Mount: Designed for mounting on equipment panels or enclosures.
End-Launch: Specifically designed for PCB edge connections with precise impedance control.
Installation and Maintenance Tips
To maximize the lifespan and performance of your 2.92 mm connectors:
Ensure Proper Torque: Recommended coupling torque is typically between 0.8 Nm to 1.1 Nm.
Avoid Over-tightening: Excess torque can damage threads or deform the connector.
Clean Contacts Regularly: Use proper cleaning tools to maintain gold-plated contacts free of debris.
Inspect for Wear: After 500 mating cycles, inspect connectors for mechanical wear or signal degradation.
Use Compatible Cables: Match connectors with appropriate semi-rigid or conformable coaxial cables like RG-405 or Times Tflex 405.
