| Temperature range | -65~+165℃ | Insulafion resistance | ≥5000MQ | ||
| Characteristic mpedance | 50Ω | withstanding votage | 4000V(rms) | ||
| Frequency range | DC~7.5GHz | VSWR | Straight | ≤1.25 | |
| Votage rating | 2700V(rms) | Right angle | ≤1.40 | ||
| Contact res istance | Center conductor | ≤0.001Ω | Durabity | 500 Cycles | |
| Outer oonductor | ≤0.0005Ω | ||||
