In the world of RF and microwave communications, connectors play a crucial role in ensuring signal integrity and reliability. Among these, the TNC Male Connector stands out as a versatile, durable, and high-frequency capable solution. Whether you're working with coaxial cables in industrial setups, military applications, or broadband wireless systems, understanding the features and benefits of TNC male connectors can significantly impact your project's success.
| Parameter | Value |
| Article No. | TNC-JW4Y |
| Frequency range | 0 ~ 4GHz |
| Impedance | 50Ω |
| VSWR | ≤1.50 |
| Withstanding voltage | 1500V |
| Insulation resistance | 5000MΩ |
| Connector type | TNC-Women interface |
| Standard | IEC60169-4 |
| Parameter | Value |
| Waterproof degree | NO |
| Moisture resistance | NO |
| Mating cycles | ≥500 |
| Outer dimension | 28*24.8*16mm |
| Parameter | Value |
| Operating temperature range | -65℃～+165℃ |
| Storage temperature range | -30℃～+60℃ |
| Connector parts | Material | Plating |
| Center conductor | Brass | Gilding |
| Outer conductor | Brass | Nickeling |
| Dielectric | PTFE | / |
| Salt mist | 96H |
| Standard | 300pc/plastic bag in separate carton |
