The BMA Connector (Blind Mate A) is a type of RF coaxial connector developed to provide quick, reliable, and high-density connections without the need for threaded coupling. Unlike traditional RF connectors that require screwing, the BMA connector uses a push-on blind-mate design that enables fast and secure mating even in confined spaces.
| Parameter | Value |
| Article No. | BMA-JY3Y |
| Frequency range | 0 ~ 12GHz |
| Impedance | 50±1.5Ω |
| VSWR | ≤1.3 |
| Withstanding Voltage | 1000V |
| Rated Power | 100W |
| Connector Type | BMA-Women interface |
| Standard | IEC60169-4 |
| Parameter | Value |
| Waterproof degree | NO |
| Moisture resistance | NO |
| Mating cycles | ≥500 |
| Outer Dimension | 23*12mm |
| Parameter | Value |
| Operating temperature range | -30℃～+120℃ |
| Storage temperature range | -30℃～+60℃ |
| Connector parts | Material | Plating |
| Center conductor | Brass | Gilding |
| Outer conductor | Brass | Silver |
| Dielectric | PTFE | / |
| Salt Mist | 96H |
| Standard | 5000pc/plastic bag in separate carton |
