In the world of RF (radio frequency) and microwave communications, precision and reliability are paramount. Whether you're working with telecommunications, instrumentation, or antenna systems, the quality of your connectors can make or break your signal integrity. Among the most trusted and widely used connectors is the SMA female connector. Known for its compact design, excellent electrical performance, and sturdy construction, the SMA female connector plays a critical role in ensuring seamless connectivity in high-frequency applications.
| Parameter | Value |
| Article No. | SMA-KY3 |
| Frequency range | DC ~6GHz |
| Impedance | 50Ω |
| VSWR | ≤1.30 |
| Withstanding voltage | 1500V |
| Insulation resistance | 5000MΩ |
| Connector type | SMA-female interface |
| Standard | IEC60169-4 |
| Parameter | Value |
| Waterproof degree | NO |
| Moisture resistance | NO |
| Mating cycles | ≥500 |
| Outer dimension | 20*6*13mm |
| Parameter | Value |
| Operating temperature range | -65℃～+165℃ |
| Storage temperature range | -30℃～+60℃ |
| Connector parts | Material | Plating |
| Center conductor | Brass | Gilding |
| Outer conductor | Brass | Silver |
| Dielectric | PTFE | / |
| Salt mist | 96H |
| Standard | 3600pc/plastic bag in separate carton |
