Applications of MMCX Right Angle Plugs
Thanks to their compact size and excellent RF performance, MMCX right angle plugs are widely used across multiple industries:
Wireless Communication Devices: Smartphones, PDAs, and Wi-Fi cards often utilize MMCX connectors for antenna connections.
GPS Receivers: Reliable signal transmission in compact GPS modules.
In-Ear Monitors (IEMs): Popular for detachable cables, allowing users to replace or upgrade cables easily.
Satellite Communication (SATCOM): Used in base stations and portable satellite devices.
Audio Equipment: High-fidelity audio devices benefit from low-loss, secure connections.
Automotive Electronics: Used in telematics and vehicular communication systems.
Medical and Aerospace: Non-magnetic variants available for sensitive environments.
Installation and Assembly Tips
To ensure optimal performance and longevity of your MMCX right angle plug:
Choose the right cable: Match the connector with compatible cables like RG174 or micro-coaxial cables (1.37 mm diameter).
Proper termination: Use crimp or solder termination per manufacturer guidelines for secure attachment.
Avoid excessive bending: Although right angle plugs reduce cable stress, avoid sharp bends near the connector.
Use high-quality tools: Crimping and soldering require precision tools to maintain connector integrity.
Test post-installation: Verify VSWR and continuity to ensure signal quality.
