Type N Panel Mount Female Connectors combine electrical performance with mechanical robustness and environmental resilience.Panel mount refers to the method of mounting the connector on a panel or enclosure, typically using a flange with four holes for screws, ensuring mechanical stability and ease of integration into RF equipment or PCB assemblies.
| Parameter | Value |
| Article No. | N-50KFD12 |
| Frequency range | DC ~6GHz |
| Impedance | 50Ω |
| VSWR | ≤1.30 |
| Withstanding voltage | 1500V |
| Insulation resistance | 5000MΩ |
| Connector type | SMA-Women interface |
| Standard | IEC60169-4 |
| Parameter | Value |
| Waterproof degree | NO |
| Moisture resistance | NO |
| Mating cycles | ≥500 |
| Outer dimension | 34*23*23mm |
| Parameter | Value |
| Operating temperature range | -65℃～+165℃ |
| Storage temperature range | -30℃～+60℃ |
| Connector parts | Material | Plating |
| Center conductor | Brass | Gilding |
| Outer conductor | Brass | Nickeling |
| Dielectric | PTFE | / |
| Salt mist | 96H |
| Standard | 500pc/plastic bag in separate carton |
